Free public access

Source-backed architecture

Paste a public GitHub repo URL to generate an evidence-backed system model.

Analyze a public repo
  • Public repos only
  • Temporary workspace
  • Export before expiry
Arcwoven repository evidence flowing into a reviewable architecture model

Arcwoven

Architecture from real evidence, not guesswork.

Most architecture diagrams are either manually drawn, outdated, or disconnected from the code. Arcwoven helps teams build architecture views directly from repository evidence, so the model stays grounded in how the system actually works. With Arcwoven, teams can see system boundaries, services, APIs, data stores, dependencies, implementation details, and source evidence in one place.

System boundaries
Implementation details
Source evidence
Arcwoven overview for software-heavy systems: source-backed architecture, SysML v2-ready export, large repositories, traceable implementation views, and private pilot delivery.
01

Import evidence

Code, configs, docs, APIs

02

Review

Generated, provisional analysis

03

Model

Human-reviewed architecture

04

Export

Diagrams, docs, HTML, SysML v2
